Zebra RFD9090 Long Range Ultra-Rugged UHF RFID Sled Reader

RFD9090 Ultra-Rugged RFID SLED Handheld Reader by Zebra offers Bluetooth and Wi-Fi capabilities, long read range of 75 feet, and 1300+ tags/sec read rate, and connects with Android/iOS smartphones.

Write a review
Features
Brand: Zebra
Operating Frequency: 865 - 867 MHz
Communication Protocol: ISO 18000-6C EPC Class 1 Gen 2
Read Range: Up to 22.9m
Power: Quick-Release, PowerPrecision+ Li-Ion 7,000 mAh battery
Notification: Bluetooth Status LED, Wi-Fi Status LED, Decode LEDs, Battery Status LED, Beeper
Enquire Now
Be the first to review this item
 Write a review

The Zebra RFD9090 UHF RFID SLED Reader is an industrial-grade handheld device that uses radio waves to identify and track tagged items. This advanced SLED RFID Handheld is compatible with EPCglobal gen 2 v2, ISO 18000-6C communication protocols, and offers extremely high performance in demanding commercial and industrial applications. With 6-foot drop-resistant, IP65, and IP67 ratings, the RFD9090 model is built to handle tough conditions, making it dustproof, sprayproof, and waterproof.

The RFD9090 SLED by Zebra features a smartphone attachment slot, a pistol grip trigger, and user-programmable buttons for one-handed operations in high-volume applications. Additionally, Wi-Fi 6, Bluetooth 5.3, and NFC tap-to-pair connectivity enable seamless device management and data transfer.

The Zebra RFD9090 Handheld SLED delivers impressive read ranges, with a standard option of 22 feet and an extended option reaching a remarkable 75 feet. This allows you to capture data from tags on items at a distance, improving efficiency and accuracy in your operations. With a 7000 mAh battery and 1300+ tags per second read rate, the Zebra portable RFID scanner is ideal for high-volume applications like inventory management or asset tracking in dynamic environments.

Applications of Zebra RFD9090 UHF RFID SLED Reader

• Baggage tracking and item locating in Logistics and Transportation

• WIP and RTO tracking in Manufacturing and Production

• Asset tracking and chain of custody in Government Applications

Specifications
Operating Frequency 865 - 867 MHz
Communication Protocol ISO 18000-6C EPC Class 1 Gen 2
Read Range Up to 22.9m
Power Quick-Release, PowerPrecision+ Li-Ion 7,000 mAh battery
Notification Bluetooth Status LED, Wi-Fi Status LED, Decode LEDs, Battery Status LED, Beeper
User Input Tri-Function User Programmable Trigger
Fastest Read Rate 1300+ tags/sec
Dimensions 248mm x 96.3mm x 173mm
Operating Temperature -20°C to 55°C
Storage Temperature 40°C to 70°C
IP Ratings IP65 and IP67
Drop Specification Multiple 6 ft./1.8 m drops to concrete
Tumble Specification 500 cycles
Electrostatic Discharge +/-15kV air discharge, +/-8kV direct discharge, +/-8kVdc indirect discharge
Humidity 5-85% non-condensing
