Long Read Range UHF/Passive RFID Reader, 1 Antenna Ports, Ethernet, USB, 802.3af PoE & PoE+, Receive Sensitivity: -84 dBm, EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)

Write a review
Features
Brand: Impinj
Operating Frequency: 865–867 MHz Ultra High Frequency(UHF)
Communication Protocol: ISO 18000-6C EPC Clas 1 Gen 2
Transmit Power (POE): +10 to +30 dBm
Transmit Power (External DC Power): +10 to +30 dBm (Listed/Certified power supply)
Max Receive Sensitivity: -84 dBm
Enquire Now
Be the first to review this item
 Write a review

The R120 Single Port UHF RFID Reader is a high-performance RFID reader designed to provide reliable performance in a wide range of applications. It is designed to read UHF RFID tags and provides a high read rate with a large read zone. It is also designed to be robust and reliable in harsh environments. The R120 is easy to set up and use, making it ideal for a wide range of applications. It is also compatible with most major RFID tag standards and can be used with a variety of antennas. It's designed for easy integration into any system and can be connected via USB, Ethernet, or Serial.

Application

• Retail Management

• Healthcare Management

• Logistics and Manufacturing

• Automotive Management

• Education Management

• Libraries Management

• Animal Tracking Management.

Specifications
Operating Frequency 865–867 MHz Ultra High Frequency(UHF)
Communication Protocol ISO 18000-6C EPC Clas 1 Gen 2
Transmit Power (POE) +10 to +30 dBm
Transmit Power (External DC Power) +10 to +30 dBm (Listed/Certified power supply)
Max Receive Sensitivity -84 dBm
Max Read Rate Up to 1,100 tag reads per second
Data Interface RS-232, ethernet
GPIO 4 GPI optically isolated 3-30V/ 4 GPO optically isolated, 0-30V, non-isolated 5V, 100mA supply (DB-15)
Power Source (POE) IEEE 802.3af
Power Source (External DC Power) Listed/Certified power supply, AC-DC power supply rated for 24Vdc/2.1A
Antenna Port 1 RP-TNC female port (connects to RP-TNC male), expandable to 8 antennas with Impinj Speedway Antenna Hub
Dimensions 190.5 x 175.3 x 30.5 mm
Weight 0.7 kg (1.5 lbs)
Operating Temperature -20 ºC to +50 ºC (-4 ºF to +122 ºF)
