IMPINJ Speedway R220 2 Port Fixed Long Range RFID Reader

Long Read Range UHF/Passive RFID Reader, 2 Antenna Ports, Ethernet, USB, 802.3af PoE & PoE+, Receive Sensitivity: -84 dBm, EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)

By Impinj
i
Write a review
Features
Communication Protocol: GS1/EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency: UHF (860- 960 MHz), region dependent
Transmit Power (POE): +10.0 to +31.5 dBm (EU1 limited to +30 dBm)
Transmit Power (External DC Power): +10.0 to +32.5 dBm (Listed/Certified power supply) (EU1 limited to +31.5 dBm, JP2 limited to 30 dBm)
Max Receive Sensitivity: -84 dBm
Enquire Now
Be the first to review this item
 Write a review

The Impinj Speedway R220 2 Port Fixed Long Range RFID Reader delivers the performance, quality, and reliability necessary for maximum visibility of tagged inventory and assets. Speedway readers are a strong component of item visibility platform solutions, capable of maintaining high read rates in the face of RF noise or interference as the readers adjust automatically for optimum functionality..

The R220 2 Port Fixed Long Range RFID Reader is a high-performance, long-range reader designed for applications requiring long read distances and fast tag read rates. The reader features two antenna ports that can be connected to either an external antenna or a built-in antenna for increased performance. It is a fixed reader, which requires no movement to scan tags, and it can read both EPC Gen2 and ISO 18000-6C tags.

Application

• Retail Inventory Management

• Medical Equipment Tracking

• Logistics and inventory tracking

• Manufacturing and production

• Asset Tracking

• Other Industries

Specifications
Communication Protocol GS1/EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency UHF (860- 960 MHz), region dependent
Transmit Power (POE) +10.0 to +31.5 dBm (EU1 limited to +30 dBm)
Transmit Power (External DC Power) +10.0 to +32.5 dBm (Listed/Certified power supply) (EU1 limited to +31.5 dBm, JP2 limited to 30 dBm)
Max Receive Sensitivity -84 dBm
Max Read Rate Up to 200 tag reads per second
GPIO 4 GPI optically isolated 3-30V/ 4 GPO optically isolated, 0-30V, non-isolated 5V, 100mA supply (DB-15)
Power Source (POE) IEEE 802.3af
Power Source (Power Adapter) Listed/Certified power supply, AC-DC power supply rated for 24Vdc/2.1A
Dimensions 190.5 x 175.3 x 30.5 mm
IP Rating IP 52
Operating Temperature -20 ºC to +50 ºC
Antenna Port 2 RP-TNC female ports (connects to RP-TNC male), monostatic
