The industrial world is changing rapidly and with that, we must change as well. The industries today demand full automation, speed, precision, and dependability without compromise. While industries face increasingly more challenges such as labor shortages, stricter compliance rules, uncertainty, and supply chain interruptions, the rapidly evolving customer expectations in terms of timeline, quality, transparency, and customization just add to the problems these businesses face.
To overcome many of these challenges, EnCstore offers a wide range of industrial fixed scanners and machine vision product solutions designed by Zebra Technologies to withstand high-performance environments. It includes a wide range of industrial fixed scanners (FS10, FS20, FS40, FS42, FS70, FS80, and GS20 connectivity gateway) among other solutions. Together, they offer tailored solutions that allow industries to improve quality control, track things, and enable smart automation in manufacturing, logistics, automotive, pharmaceuticals, and much more.
From lightning-fast capture of barcodes, Direct Part Marks (DPMs), and other machine-readable symbols to the seamless connectivity of the world's most complex production lines, these solutions allow organizations to track, trace, and manage every single item confidently.
Let’s see some of these industrial scanning devices in detail:
GS20 Connectivity Gateway by Zebra
GS20 is an industrial connectivity gateway for all new scan tunnel products, which provides increased practices in product package tracking in a sorted and well-aligned throughput.
GS20 is the main character, so all cameras can be connected for a single purpose and do overall barcode scanning. Supporting up to 16 cameras at a time, GS20 can scan data from each camera and access only the information needed for the host application.
It allows GS20 to eliminate processing inefficiencies and enables all of the cameras in tunnels to peak scan capacity by maximizing your return on scan tunnel investments. It is designed to work with all current and future Zebra fixed industrial scanners.
Key Specifications of GS20 Connectivity Gateway
1.Dimensions: 1.1 in. H x 2.15 in. W x 3.71 in. D (28.3 x 54.6 x 94.3 mm)
2. Power Supply: 10–30 VDC, 7W max at 24V or Class 2 PoE (7W)
3. I/O Configuration: 4 opto-isolated GPIO (2 inputs, 2 outputs)
4. Interface Ports: M12 X-Coded Ethernet (10/100/1000 Mbps), M12 12 pin Power/GPIO/Serial
5. Host to PLC: Siemens, Rockwell, Omron, Mitsubishi (TCP/IP, Serial, GPIO)
6. Leader to Followers: TCP/IP, GPIO
7. Compatible with Zebra FS20, FS40, FS70 (via TCP/IP, GPIO)
8. Operating Temp: 32°–113°F (0°–45°C)
9. Humidity: 5–90% RH (non-condensing)
10. Sealing: IP65 and IP67
11. Vibration Resistance: EN 60068-2-6 (2–500 Hz)
12. Shock Resistance: EN 60068-2-27 (30 g, 11 ms)
The GS20 comes with 2 years of warranty (as per Zebra hardware warranty statement) and supports accessories such as brackets, cables, power supplies, and external lighting accessories for an enhanced tunnel sorting operation.
EnCstore Meets All Your RFID Needs!
Get best quality RFID Readers, RFID Tags, Antennas and Printers from top brands in AIDC industry.
Visit Our RFID Store
Zebra FS80 Fixed Industrial Scanner
Higher demands always require high-value solutions and that is why Zebra FS80 is the only choice in industrial barcode scanning that provides efficient movements, end-to-end product tracking, and exact barcode data to manufacturers and logistics businesses.
Zebra’s FS80 fixed industrial scanner provides a trusted and tested solution to manage high-speed operations. It offers high-speed operations with magnificent sensors and lightning-fast focus for readability in a large area at a wide range. FS80 gives a precise data capture of the barcode.
Key Specifications of FS80 Scanner
1.Aurora Focus™ Software: Enables easy setup, deployment, and operation of the FS80.
2. Processor: Intel® Atom® x6211E (dual-core, 1.3 GHz base, 3.0 GHz burst).
3. License Upgrades: Supports Decoder Packages and Machine Vision Toolsets.
4. Sensor Options: 5 MP, 9 MP, 12 MP, and 16 MP available.
FS42 Fixed Industrial Barcode Scanner
Manufacturing, retail, logistics, commerce and supply chain departments demand efficiency and accuracy and having a high performance industrial barcode scanner can simply many operations.
The FS42 scanner is designed to step into resource-oriented applications, for deep learning-based OCR and better throughput. This fixed industrial scanner delivers accuracy and efficiency for demanding scanning applications with a sensor flexibility of 2MP and 5MP for focused and detailed images, great onboard memory, and a powerful NPU to speed up data processing.
Key Specifications of FS42 Scanner
1.Aurora Focus™ Software: Simplifies setup, deployment, and operation of the FS42.
2. Processor: New quad-core design for high-speed scanning and advanced machine vision.
3. License Upgrades: Supports Decoder Packages and Machine Vision Toolsets for expanded capabilities.
4. Communication: Ethernet/IP, PROFINET, Modbus TCP, TCP/IP, and RS 232 connectivity.
FS10 Fixed Industrial Scanner
The market of commerce and supply chain is evolving more than any other sector. These industries need a success-driven ability to quickly move and track the products without human touch. Just plug the FS10 scanner into the USB port of the available device to capture quick barcode data from assembly to storage. Being small in size, the scanner can fit everywhere, from conveyor to tunnels, item sorting desk, assembly lines, etc.
Key Specifications of FS10 Scanner
1.Aurora™ Software: Enables quick and easy setup, deployment, and operation of the FS10.
2. Image Perfect: Captures up to 3 images of a single item for enhanced inspection.
3. License Upgrades: Supports Decoder Packages for added capabilities.
4. Interface Ports: High-speed, locking USB-C 2.0 connectivity.
FS20 Fixed industrial scanner
The FS20 fixed industrial scanner by Zebra makes the task way too easy for every item to be tracked and traced as it moves toward production. It captures three different images of a single item with different setting which ensures that you get a perfect image and quick inspection of defective parts.
For real-time inventory, it scans barcodes on those items that are placed on warehouse shelves for better visibility. The FS20 is easily upgradable to a smart machine vision camera with added core machine vision capabilities, turning into a VS20 smart sensor, by purchasing the software license, no need to buy a new product.
The FS20 fixed scanner comes with PRZM Intelligent Imaging which allows it to excel at capturing barcode data, including damaged 1D and 2D codes.
Key Specifications of FS20 Scanner
-
1. Aurora™ Software: Enables quick and easy setup, deployment, and operation of the FS20.
-
2. Image Perfect: Captures up to 3 images of a single item for enhanced inspection.
-
3. License Upgrades: Supports Decoder Packages and Machine Vision Toolsets.
-
4. Communication: Ethernet/IP, PROFINET, Modbus TCP, TCP/IP, RS 232.
FS40 Fixed industrial scanner
Talking about the overall production and delivery process, the FS40 fixed industrial scanner is here to be addressed. FS40 is introduced for fast-moving operations, tracking and tracing, and automatic and flawless decoding of information on every product package while moving through production and storage.
FS40 results in first-class production, warehousing, and logistics processes, inspiring businesses to raise their potential for success.
Key Specifications of FS40 Scanner
1. Aurora™ Software: Enables quick and easy setup, deployment, and operation of the FS40.
2. Image Perfect+: Processes up to 16 images simultaneously for higher read rates.
3. License Upgrades: Supports Decoder Packages and Machine Vision Toolsets.
4. Interface Ports: Single or dual Ethernet, PoE, USB C, 5-pin external light & GPIO, 12-pin power/GPIO/RS 232.
FS70 Fixed industrial scanner
The FS70 fixed industrial scanner is designed to help commerce and supply chain departments keep ahead in production, storage, and fulfilment. It is an entirely configurable and customized solution that ranges from precision quality control for wholesome track and trace to delivering performance and flexibility that needs to be optimized in every aspect of the supply chain.
FS70 can effectively work with any type of external lighting, which can solve any trickiest barcode challenges, low contrast direct part marks, or curved or reflected surfaces.
Key Specifications of FS70 Scanner
1.Aurora™ Software: Enables quick and easy setup, deployment, and operation of the FS70.
2. ImagePerfect+: Processes up to 16 images simultaneously for higher read rates.
3. License Upgrades: Supports Decoder Packages and Machine Vision Toolsets.
4. Interface Ports: Single or Dual Ethernet, PoE, USB C, 5-pin External Light Power & Control/GPIO, 12-pin Power/GPIO/RS 232.
Finally, industrial scanning has changed drastically requiring more clear, fast, and accurate data scanning, and that is where Zebra fixed industrial scanners excel. Whether it is FS10, GS20, FS40, or FS80, these fixed scanners help with sorting, inventorying, damage detection and more.
EnCstore.com offers these premium fixed industrial scanners in India at industry best prices, with pan-India shipping. Whether you need Zebra RFID Readers, Zebra Printers, Antennas or Zebra industrial scanning and machine vision solutions, get in touch today.
