URA4 fixed Android RFID Reader, Wall Mounted 4G RFID Reader

The URA4 4-port long read range UHF RFID Android reader is a high performance, wall-mountable RFID fixed Reader which supports RS232, RJ45(POE / POE+), HDMI, USB, and GPIO connectivity.

Write a review
Features
Operating Frequency: 865 - 928 MHz
Communication Protocol: EPCglobal UHF Class 1 Gen 2 v2 (ISO 18000-63)
Max Receive Sensitivity: < -84dBm
Max Read Distance: 900+ tags/sec
GPIO: 4 Input Optical-couplings, 4 Output Optical-ouplings, isolation, 1 Wiegand (optional)
Enquire Now
Related Products
Impinj R720 RAIN RFID Reader - Fixed Mount, 4 Antenna Ports
Zebra FX7500 Fixed UHF RFID Reader, 4 Antenna Ports, PoE
Impinj R120 UHF RFID Reader (1 Port)
Impinj R420 RFID Reader - UHF, 4 Ports, Fixed & IoT Enabled
Zebra FXP20 RFID Fixed Reader for Point of Sale
Be the first to review this item
 Write a review



URA4 fixed Android RFID Reader is a high-performance RFID reader that reads 900+ tags per second and features a large touchscreen display, a high-powered radio frequency (RF) antenna, and an internal battery that can last up to 12 hours.

EnCStore offers these RFID Fixed Readers that can read and write to a wide variety of RFID tags, including HF, UHF, and NFC at market best prices. These also support ISO 18000-63 EPCGlobal Gen2v2  communication protocols and are compatible with major RFID software solutions.

These long-range RFID readers also feature a built-in buzzer and LED indicators, making it easy to use and configure with a variety of RFID tags. It also has an internal antenna and a USB port for connecting to a computer. With its versatile features and reliable performance, the URA4 passive RFID reader is a great choice for many commercial and industrial RFID applications as follows:

Applications of URA4 Fixed Android RFID Reader

• Access Control,

• Asset Tracking,

• Library Management,

• Logistics and inventory tracking, and

• Manufacturing and production.



Specifications
Operating Frequency 865 - 928 MHz
Communication Protocol EPCglobal UHF Class 1 Gen 2 v2 (ISO 18000-63)
Max Receive Sensitivity < -84dBm
Max Read Distance 900+ tags/sec
GPIO 4 Input Optical-couplings, 4 Output Optical-ouplings, isolation, 1 Wiegand (optional)
Power Source DC (12V), POE (802.3af 13W), POE+ (802.3at 25.5W)
RAM + ROM 3 GB + 32 GB, 2 GB + 16 GB (optional)
Processor Qualcomm 1.8 GHz Octa-core
Material Aluminium alloy
Dimension 214mm (L) x 148mm (W) x 30mm(D)
Antenna Ports 4 channel 50 Ohm TNC port
Operating System Android 9.0
Communication Interface 1*RS-232 , 1*RJ45, 3*USB2.0 Type A, 1*Type C, USB Host
Mounting Wall Mount
Weight 1000g
Operating Temperature -25°C to +65°C
Storage Temperature -40°C to +85°C
