The SR160 Handheld UHF RFID Scanner works on 865-867 Mhz (UHF) frequency, offers 1D/2D barcode scanning, a upto 30m read range, best-in-class high performance Wired RFID scanner for Inventory Tracking

Write a review
Features
Brand: Chainway
Operating Frequency: 865-867 Mhz, Ultra High Frequency (UHF)
Air Interface Protocol: ISO 18000-6C EPC Clas 1 Gen 2
Antenna Type: Circular Polarized Antenna
Bluetooth: Bluetooth 5.0 (Optional)
Communication Interface: RJ45 interface,HID USB
Enquire Now
Be the first to review this item
 Write a review

Chainway SR160 Handheld Wired UHF RFID Scanner lightweight, and portable RFID reader and supports both UHF RFID and 1D/2D scanning. Using self-developed UHF RFID modules based on the Impinj E310 chip and providing excellent single-tag reading performance, SR160 can scan multiple tags quickly and correctly with a maximum reading range of more than 30cm.  The scanner also has a high-performance barcode scan engine that can capture a variety of 1D/2D barcodes. The reader has a durable IP54 rating, making it dust and water-resistant.

Application of SR160 Handheld Wired UHF RFID Scanner

• Inventory management,

• Asset tracking,

• Warehouse management,

• Document authentication, and more.

Specifications
Operating Frequency865-867 Mhz, Ultra High Frequency (UHF)
Air Interface ProtocolISO 18000-6C EPC Clas 1 Gen 2
Antenna TypeCircular Polarized Antenna
BluetoothBluetooth 5.0 (Optional)
Communication InterfaceRJ45 interface,HID USB
Dimensions154mm x 87.8mm x 65.0mm
MaterialPlastic
Output Powerupto 25 dBm
Max Read Rangeupto 30 cm
Power Supply5V 2A
Battery2600mAh (Wireless Version)
KeypadPower key / scan key
ButtonUHF or 2D
Output Power Precision±1dBm
