9dBi Linear Polarized UHF RFID Shelf Antenna

860-960MHz Frequency, High-Performanc, 3W max input power, IP Rating-65, suitable for real time asset and inventory management

Get Latest Price
Operating Frequency: 865–867 MHz Ultra High Frequency(UHF)
Polarization: Linear
Connector Type: SMA female standard
Antenna Gain: 9 dBi
Dimensions: 600 mm x 250 mm x 8 mm
Enquire Now

Linear Polarized Shelving and cabinet antenna are especially designed for existing shelving systems, and come with a sleek, aesthetic form factor suitable for customer facing environments and provide strong performance over the entire frequency range of 865–867 MHz with Gain 9.0 dBi.

Application: Vehicle fleet management, shelving systems, Real-time asset and inventory management

Operating Frequency 865–867 MHz Ultra High Frequency(UHF)
Polarization Linear
Connector Type SMA female standard
Antenna Gain 9 dBi
Dimensions 600 mm x 250 mm x 8 mm
IP Rating IP65
Operating Temperature -20° to +55°C
Storage Temperature -30° to +65°C
Maximum Input Power 3 W
Nominal impedance 50 ohm
